The Jonsbo TK-4 is an impressive mid-tower case with a timeless design made of steel, aluminium, and tinted tempered glass side panels. Ideal for hardware enthusiasts seeking maximum cooling options and a showcase-worthy case.
Showcase your hardware perfectly with the TK-4 PC case. The generous panoramic design with glass front and sides offers a clear view of your components at all times – ideal for eye-catching builds with RGB lighting and custom water cooling.
The solid steel-aluminium construction ensures both stability and durability. Thanks to the symmetrical layout, the system remains tidy at all times.
The mid-tower offers the perfect balance between size and functionality. With ample space for powerful hardware and efficient cooling, it is the ideal choice for gaming and workstation builds.
The case accommodates up to three 140mm fans at the top, bottom, and side, as well as two 92mm fans at the rear. For custom water cooling, there are mounts for radiators up to 420mm – perfect for extreme builds with high heat output.
Thanks to back-connect support, your build in the Jonsbo TK-4 looks like it’s from a distant future – no visible cables, just maximum order, perfect airflow, and uncompromising design. With its clever dual-chamber design, the case also ensures optimized cooling and less cable clutter.
Thanks to the removable dust filters, your case stays free from dust deposits. The filters are easy to clean, keeping your computer optimally cooled at all times.
Supporting ATX, mATX, and ITX motherboards, as well as space for multiple 2.5-inch and 3.5-inch drives, the TK-4 offers enormous flexibility. The USB-C port on the front allows quick access to modern peripherals – ideal for demanding users.
| Case Features | |
| I/O position | Front |
| Side panel | with window |
| Vertical GPU Mount | No |
| Adjustable Vertical GPU Bracket | No |
| Front door | No |
| Cable Management | Yes |
| Filters Included | Yes |
| Filter Position | Bottom |
| Noise dampening | No |
| Mainboard slide / tray | No |
| Transport System | No |
| Back Connect | |
| Back Connect | No |
| Radiator Support | |
| Radiator/AIO Support (Top) | 360mm Radiator, 420mm Radiator |
| Max. Radiator Compatibility | 2x Triple (420 mm) |
| Radiator/AIO Support (Bottom) | 360mm Radiator, 420mm Radiator |
| Colour | |
| Primary Colour | Black |
| Motherboard Support | |
| Compatible Motherboard Formats | ATX, Micro-ATX, Mini-ITX |
| Max. Motherboard Format | ATX |
| Power Supply | |
| PSU included | No |
| PSU Format | ATX |
| Power Supply Position | rear side |
| Case | |
| Case Type | Mid Tower |
| Lighting | |
| Lighting / RGB | No |
| Compliance | |
| Compliance Documents | Jonsbo PC Case Compliance and Safety |
| Display | |
| Display Included | No |
| Fan Support | |
| Case Fan Support (Rear) | 92mm Fan (2x) |
| Case Fan Support (Side) | 120mm Fan (3x), 140mm Fan (3x) |
| Case Fan Support (Bottom) | 120mm Fan (3x), 140mm Fan (3x) |
| Case Fan Support (Top) | 120mm Fan (3x), 140mm Fan (3x) |
| Max. Number of Fans | 11 |
| 92 mm fans | 2 |
| 120 mm fans | 9 |
| 140 mm fans | 9 |
| Dimensions | |
| Length / Depth | 495 mm |
| Width | 298.6 mm |
| Height | 495 mm |
| Weight | 10.72 kg |
| Drive Bays | |
| Max. 2.5 Inch Drives | 2 |
| Max. 3.5 Inch Drives | 4 |
| Max. 5.25 Inch Drives | 0 |
| 1x 3.5 / 1x 2.5 Inch Internal Drive Bays (combined) | 2 |
| Hot swap drive bays | No |
| External Ports | |
| Front I/O – USB Type C Ports Total | 1 |
| Front I/O – USB Type A Ports Total | 1 |
| USB 3.2 (external) Type C | 1 |
| USB 3.0 (external) Type A | 1 |
| Audio outputs & inputs | 1x output / input comb. (3.5 mm jack, 4-pin, TRRS) |
| Card reader | No |
| Mounting | |
| Internal Monitor Mount | No |
| Case VESA Mountable | No |
| Internal Dimensions | |
| Max. CPU Cooler Height | 175 mm |
| Max. GPU Length | 460 mm |
| Max. PSU Length / Depth | 200 mm |
| Fan Header | |
| Fan Controller / Fan Hub | No |
| Expansion Slots | |
| Expansion slots / PCI slots | 8 |
| Additional Contents | |
| Fans Included | No |
| Included fans | None |
| Features | |
| Housing Feedthrough | No |
| Materials | |
| Materials | Steel, Glass |
| Cable Specifications | |
| Riser Cable Included | No |
