HAVN HS 360 Black Panoramic Glass ATX PC Case

The Black HAVN HS 360 is a mid-tower ATX case with a panoramic UniSheet tempered glass side panel and a 61.9 L interior. It measures 490.9 × 242.1 × 520.9 mm and accepts ATX, BTF ATX (back connect), Micro-ATX and Mini-ITX motherboards. Compared with the HS 420, it is 19.4% smaller and 29.5% lighter.

Key Features

• Panoramic glass side panel: UniSheet tempered glass with a 7.5 mm corner radius, mounted with magnets and rollers.
• Fan support: up to eleven 120 mm fans, with three at the top, three on the right, three at the bottom and two at the rear. Rear fans can be up to 30 mm thick.
• Radiator support: 360 mm radiators at the top, right and bottom, subject to thickness and component restrictions. A bottom radiator fits at 109 mm with a one-slot GPU, or at 120 mm with the GPU support removed.
• Dust filtration: built-in filters on the top and right intakes, and removable filters on the bottom and lower rear.
• Cable management: SimpliCable routing and an 8-channel PWM repeater on the cable management tray.

Compatibility

• Motherboards: ATX, BTF ATX (Back Connect ATX, switchable between standard and back-connect modes), Micro-ATX and Mini-ITX.
• Graphics cards: up to 430 mm long and 180 mm wide, with up to five slots from the second expansion slot or four slots from the third. The case has seven expansion slots.
• CPU coolers: up to 170 mm tall. Liquid cooling is recommended.
• Power supplies: ATX, SFX or SFX-L, up to 230 mm long (300 mm clearance).
• Storage: two storage bays included. Each bay takes either 3.5-inch or 2.5-inch drives.

Front I/O

• 1 × USB 3.2 Gen 2 Type-C
• 2 × USB 3.2 Gen 1 Type-A
• 1 × combo audio jack
• Power button
