Flow Luxury
F-LUX Platform, abbreviation of Flow Luxury, features ultra case structure design for excellent airflow and 6 fans included, delivering enhanced GPU cooling performance.
Flux Airflow
Multi-directional vent design, featuring extensive air intakes at the bottom, power supply chamber and lower sides, along with top vents and large-area mesh at the front, creating a dedicated Antec Flux airflow channel.
Flux Vertical Cooling
Air intake via the PSU chamber maximizes heat dissipation while enhancing the intake effect for the graphics card.
Flux Horizontal Cooling
Air intake via the front mesh provide smooth venting channel throughout the case.
Premium Wood Material
Front panel is crafted with a combination of metal mesh and wood (walnut) to create a high-quality texture with different materials, integrating seamlessly into your home design.
Innovative iShift PSU Mount
In addition to the standard PSU mount orientation, a 90-degree rotated option powered by the included extension cable is available.
CPU/GPU Dual Temperature Display
Innovative hardware temperature display design with 4 modes.
Antec iUnity
The Antec iUnity provides instant data on PC specs, loads and usage.
Removable Top Cooling Bracket
Mount the fans/radiators on the cooling bracket first and install the cooling bracket back to the case.
Removable Cooling Bracket on Top Off PSU Shroud
When fans (2 available) are installed on the case bottom, remove the top shroud bracket to maximise airflow, fulfilling the optimal vertical cooling scheme.
Removable Front Cooling Bracket
Vertically adjustable to 5 positions to fit the huge top AIO.
Recommended Water Cooling
Supports simultaneous installation of Front 360mm radiator + Top 420mm radiator.
Support Vertical GPU Mount with Vertical Bracket
Fully-open PCI slot covers can be removed to install the graphics card vertically.
Bottom Full-Size Pull-Out Dust Filter
For easy cleaning and strong dust prevention.
| main spec |
| Dimensions |
530 x 245 x 545 mm (DWH) |
| Form Factor |
Full Tower |
| Materials |
Steel + Plastic + Glass + Wood |
| Mainboard Support |
E-ATX (≤285mm), ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, Reset, USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack, Temp. Display Switch x 1 |
| Side Panel |
4mm Tempered Glass |
|
| Drive Bays |
| Expansion Slots |
8 |
| 3.5" /2.5" |
4/4 |
| 2.5" |
2 |
|
| Fan Support |
| Front |
3 x 120mm / 3 x 140mm |
| Top |
3 x 120mm / 3 x 140mm |
| Power Supply Shroud |
3 x 120mm |
| Bottom |
2 x 120mm / 2 x 140mm |
| Rear |
1 x 120mm / 1 x 140mm |
| Included Fan(s) |
3 x 140mm Tranquil PWM fans in front + 2 x 120mm P12R PWM reverse fans on PSU shroud
+ 1 x 140mm Tranquil PWM fan in rear |
|
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360 / 420mm |
| Top |
120 / 140 / 240 / 280 / 360 / 420mm |
| Power Supply Shroud |
120 / 240 / 360mm |
| Bottom |
120 / 240mm |
| Rear |
120 / 140mm |
|
| Clearance |
| Max GPU Length |
≤ 455mm |
| Max CPU Cooler Height |
≤ 190mm |
| Max PSU Length |
(Include cable) ≤ 180 / 300mm (with HDD)
(Include cable) ≤ 470mm (without HDD)
(Not Include cable) ≤ 180mm (Side Mount) |
|
| Miscellaneous |
| Dust Filter |
Bottom |
| Net Weight |
13.60 Kg |
| Gross Weight |
16.65 Kg |
| Warranty |
2 Years |
| UPC# |
0761345101547 |
|
