650W NZXT C650 80+ Bronze Semi-Modular PSU

KEY SPECS

• Dimensions:W 150 x L 140 x H 86 (mm)

• Material(s):Steel, PCB and plastic

• Compliance Standard:ATX12V v2.4 / EPS12V v2.92

• AC Input Rating:10A/115V；5A/230V 47Hz ~ 63Hz

DC OUTPUT RATING

• Voltage:+3.3V / +5V / +5VSB /+12V / -12V

• Max Load:20A / 20A / 2.5A / 54A / 0.3A

• Voltage Regulation:±5% / ±5% / ±5% / ±5% / ±10%

• Ripple & Noise:< 50 mV p-p / < 50 mV p-p / < 50 mV p-p / < 120 mV p-p / < 120 mV p-p

• Output Power (watt):110 / 110 / 12.5 / 648 / 3.6

• Total:650

FAN SPECS

• Dimensions:120 x 120 x 25 (mm)

• Speed:2400 ±10% RPM

• Airflow:72.90 CFM

• Noise:<44 dBA

• Bearing:FDB (Fluid Dynamic Bearing)

ENERGY EFFICIENCY

• Rating:80 Plus Bronze

• 10% loading:82%

• 20% loading:83%

• 50% loading:87%

• 100% loading:83%

OPERATION

• PF Correction:Active@0.96

• MTBF:100,000 hours

• Operation Temperature:0 to 40°C

OUTPUT CONNECTOR(S)

• 24-pin ATX Power:1

• 4+4-pin CPU power:2

• 6+2-pin PCIe power:4

• SATA Power:6

• Peripherals:3
